Binary Sequence Correlation Tool

This online tool computes the correlation of periodic binary sequence. In particular, maximum length Linear Recursive Sequences (LRS) have distinct autocorrelation properties.

Binary Sequence

For correlation, ones and zeros are replaced by +1 and -1 respectively

1000010110101000111011111001001
+----+-++-+-+---+++-+++++--+--+

Correlation Result

The correlation of a sequence with itself is autocorrelation. The autocorrelation result has a period of 31 bits corresponding to the length of the supplied sequence. The graph shows two full periods of the autocorrelation result.

31 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1

Correlation

Input Sequences

Enter two binary sequences (A,B) to be correlated. For autocorrelation, only the first sequence (A) is required.

Binary Sequence A:
Binary Sequence B:
Example Maximum Length Sequences: [ 7-bit ] [ 15-bit ] [ 31-bit ] [ 63-bit ]

Special Sequences - Barker Code

Each Barker code below may also be inverted and bit-reversed. [bits]

[2] + +
[2] + -
[3] + - -
[4] + - - -
[4] - + - -
[5] + + + - +
[7] + + + - - + -
[11] + + + - - - + - - + -
[13] + + + + + - - + + - + - +

Ref: R. H. Barker, Group synchronization of binary digital systems, in Communication Theory, W. Jackson, Ed. London, U.K.: Butterworths, 1953, pp. 273-287.
